DP15TL Pressure Sensor Kit for Changing Ranges
- Ranges of ±1, ±5, ±20, ±75, ±250, ±1000, ±3000 psid
- ½% Accuracy
- Accepts corrosive liquids and gases, both sides
- High natural frequency
- Low sensitivity to line pressure
The wide range of diaphragms furnished eliminates expensive stocking of several transducers and offers the versatility of the differential type bi-directional transducer at a very low cost. The broad line pressure capability of this unit makes it useful in almost every laboratory application from flow to level measurement, vacuum to 3000 PSIG. The high output, when used with a carrier system such as the Model CD15 Sine Wave Carrier Demodulator or the CD12 Transducer Indicator, provides resolution equal to many secondary standard units.
The two symmetrical body parts are easily disassembled and reassembled with replacement diaphragm using wrench furnished. The DP15 design incorporates the vent valves for complete purging of liquid filled systems for dynamic measurements with corrosion resistant exposure to the media. Spare O-ring seals, bleed screws and gaskets are included in the handy storage box.
Features
- Ranges of ±1, ±5, ±20, ±75, ±250, ±1000, ±3000 psid
- 1/2% Accuracy
- Accepts corrosive liquids and gases, both sides
- High natural frequency
- Low sensitivity to line pressure
